C # remove the redundant white part of the picture
2022-07-20 19:16:00 【Brother Xiaohui】
/// <summary>
/// Cut the picture ( Remove the edges )
/// </summary>
/// <param name="FilePath"> Picture path </param>
public void RemoveWhiteEdge(string FilePath)
{
Bitmap bmp = new Bitmap(FilePath);
// Up, down, left, right
int top = 0, left = 0, right = bmp.Width, bottom = bmp.Height;
// Look for the top line , From the left (0) To the right , From above (0) Go down
for (int i = 0; i < bmp.Height; i++)// That's ok
{
bool find = false;
for (int j = 0; j < bmp.Width; j++)// Column
{
Color c = bmp.GetPixel(j, i);
if (!IsWhite(c))
{
top = i;
find = true;
break;
}
}
if (find)
break;
}
// Look for the leftmost line , From above (top position ) Go down , From left to right
for (int i = 0; i < bmp.Width; i++)// Column
{
bool find = false;
for (int j = top; j < bmp.Height; j++)// That's ok
{
Color c = bmp.GetPixel(i, j);
if (!IsWhite(c))
{
left = i;
find = true;
break;
}
}
if (find)
break;
}
// Find the bottom line , From bottom to top , From left to right
for (int i = bmp.Height - 1; i >= 0; i--)// That's ok
{
bool find = false;
for (int j = left; j < bmp.Width; j++)// Column
{
Color c = bmp.GetPixel(j, i);
if (!IsWhite(c))
{
bottom = i;
find = true;
break;
}
}
if (find)
break;
}
// Look for the rightmost line , From top to bottom , From right to left
for (int i = bmp.Width - 1; i >= 0; i--)// Column
{
bool find = false;
for (int j = 0; j <= bottom; j++)// That's ok
{
Color c = bmp.GetPixel(i, j);
if (!IsWhite(c))
{
right = i;
find = true;
break;
}
}
if (find)
break;
}
// Clone a part of a bitmap object .
Rectangle cloneRect = new Rectangle(left, top, right - left, bottom - top);
Bitmap cloneBitmap = bmp.Clone(cloneRect, bmp.PixelFormat);
cloneBitmap.Save(@"D:/service/123.png", ImageFormat.Png);
bmp.Dispose();
}
/// <summary>
/// Judge whether white and pure transparent color (10 Tolerance of points )
/// </summary>
public static bool IsWhite(Color c)
{
// Pure transparency is also white ,RGB All for 255 Pure white
if (c.A < 10 || (c.R > 245 && c.G > 245 && c.B > 245))
return true;
return false;
}
from Make dreams crazy
