C Language implementation Solving the inverse matrix

Recently, I just completed the review of the probability theory foundation of postgraduate entrance examination , So I began to recall the line generation shortly after the review , For the theoretical part of the matrix , I just feel that I haven't experienced code level interpretation except the routine manual calculation between paper and pen , In view of this , Then he began to look back carefully , Supplemented by the ideas of the first , So far, , In order to grasp the meaning from the lower logic , Choose to use C Language to realize functions , The following is an implementation module that can run through . What one does , Unavoidable omissions , For reference only .

Algorithm ideas

1. The identity matrix of the same row and column is spliced on the right side of the original matrix to Expand , get The number of rows remains the same 、 Column number multiplication The extended matrix of ;
2. The expanded matrix is Elementary line transformation , obtain The left half is the identity matrix The new matrix of ;
3. Intercept the right half of the new matrix , That's what you want Inverse matrix ;

• It should be noted that , Before extending the original matrix , It is necessary to determine whether it meets the extension conditions , That is, whether the original matrix has an inverse matrix .

Implementation code

#include <stdio.h>
#include <stdlib.h>

#define true 1
#define false 0

double** expand_matrix;
double** new_matrix;

void initExpandMatrix(double ** mat, double ** expand_mat, int);
int adjustMatrix(double ** expand_mat, int len);
void calculateExpandMatrix(double ** expand_mat, int len);
void getNewMatrix(double ** expand_mat, double ** new_mat, int len);
void printMatrix(double ** mat, int len);
double** getProductMatrix(double ** init_mat, double ** new_mat, int len);
double** getInvMatrix(double ** mat, int len);

int main() {

    int len;
    scanf("%d", &len);
    double** init_mat = (double **)malloc(sizeof(double *) * len);
    for (int i = 0; i < len; i++) {

        init_mat[i] = (double *)malloc(sizeof(double) * len);
    }
     /*  Test examples  1 2 -1 3 4 -2 5 -4 1 */
    for (int i = 0; i < len; i++) {

        for (int j = 0; j < len; j++) {

            scanf("%lf", &init_mat[i][j]);
        }
    }
    printf("====== init_matrix ======\n");
    printMatrix(init_mat, len);

    printf("==== inverse matrix ====\n\n");
    double ** new_mat = getInvMatrix(init_mat, len);
    printMatrix(new_mat, len);

    printf("====== init * inv ======\n\n");
    double** product_mat = getProductMatrix(init_mat, new_mat, len);
    printMatrix(product_mat, len);
    return 0;
}

// inverse matrix
double** getInvMatrix(double ** mat, int len) {

    //  Extended matrix definition  //
    expand_matrix = (double**)malloc(sizeof(double *) * len);
    for (int i = 0; i < len; i++) {

        expand_matrix[i] = (double *)malloc(sizeof(double ) * (len * 2));
    }

    //  Inverse matrix definition  //
    new_matrix = (double**)malloc(sizeof(double *) * len);
    for (int i = 0; i < len; i++) {

        new_matrix[i] = (double *)malloc(sizeof(double ) * len);
    }

    // init
    initExpandMatrix(mat, expand_matrix, len);

    // adjust
    int canAdjust = adjustMatrix(expand_matrix, len);

    if (canAdjust == 0) {

        return NULL;
    }

    // calc expand
    calculateExpandMatrix(expand_matrix, len);

    //  Take the back N*N matrix , It's what you want  //
    getNewMatrix(expand_matrix, new_matrix, len);

    return new_matrix;
}


// init expand_matrix
void initExpandMatrix(double ** mat, double ** expand_mat, int len) {

    for (int i = 0; i < len; i++) {

        for (int j = 0; j < len * 2; j++) {

            if (j < len) {

                expand_mat[i][j] = mat[i][j];
            } else {

                if (j == len + i) {

                    expand_mat[i][j] = 1;
                } else {

                    expand_mat[i][j] = 0;
                }
            }
        }
    }
}


// adjust expand matrix
int adjustMatrix(double ** expand_mat, int len) {


    for (int i = 0; i < len; i++) {

        if (expand_mat[i][i] == 0) {

            int j;
            for (j = 0; j < len; j++) {

                if (expand_mat[j][i] != 0) {

                    double* tmp = expand_mat[i];
                    expand_mat[i] = expand_mat[j];
                    expand_mat[j] = tmp;
                    break;
                }
            }
            if (j >= len) {

                printf("Inv Matrix does not exists\n");
                return false;
            }
        }
    }
    return true;
}


// calc
void calculateExpandMatrix(double ** expand_mat, int len) {

    for (int i = 0; i < len; i++) {

        double fir_ele = expand_mat[i][i];
        for (int j = 0; j < len * 2; j++) {

            expand_mat[i][j] /= fir_ele;  //  Divide all elements of the line by the first element  //
        }
        for (int m = 0; m < len; m++) {

            if (m == i) {

                continue;
            }
            //  Multiple  //
            double times = expand_mat[m][i];
            for (int n = 0; n < len * 2; n++) {

                expand_mat[m][n] -= expand_mat[i][n] * times;
            }
        }
    }
}


// get res
void getNewMatrix(double ** expand_mat, double ** new_mat, int len) {

    for (int i = 0; i < len; i++) {

        for (int j = 0; j < len * 2; j++) {

            if (j >= len) {

                new_mat[i][j - len] = expand_mat[i][j];
            }
        }
    }
}


// print matrix
void printMatrix(double** mat, int len) {

    for (int i = 0; i < len; i++) {

        for (int j = 0; j < len; j++) {

            printf("%.1lf ", mat[i][j]);
        }
        putchar('\n');
    }
    putchar('\n');
}

// matrix multiplying
double** getProductMatrix(double** init_mat, double** new_mat, int len) {

    double** product_mat = (double**)malloc(sizeof(double*) * len);
    for (int i = 0; i < len; i++) {

        product_mat[i] = (double*)malloc(sizeof(double) * len);
    }
    // need initializing to zero
    for (int i = 0; i < len; i++) {

        for (int j = 0; j < len; j++) {

            product_mat[i][j] = 0;
        }
    }
    for (int i = 0; i < len; i++) {

        for (int j = 0; j < len; j++) {

            for (int k = 0; k < len; k++) {

                product_mat[i][j] += init_mat[i][k] * new_mat[k][j];
            }
        }
    }
    return product_mat;
}

• Example test results
