Call event after the grip of CAD object is edited (COM interface VB language)

2022-07-22 06:33:00 【51CTO】

Mainly use function description ：_DMxDrawXEvents::ObjectGripEdit

After the grip of the object is edited , This event will be called , The details are as follows ：

Parameters	explain
LONGLONG lId	Object's id
LONG iGridIndex	Grip index edited

VB The code implementation is as follows ：


       ' Check whether the object is ImageMark object , And return object data .​​

​​Dim data As MxDrawXLib.MxDrawResbuf​​

​​Set data = MxDrawX1.CallLongParam1("Mx_GetImageMarkData", lId)​​

​​If data.AtString(0) = "Ok" Then​​

​​'​​​ ​​ obtain Mark The file name of the object .​​

​​MsgBox (data.AtString(1))​​

​​' The insertion point x​​

​​MsgBox (data.AtDouble(2))​​

​​'​​​​ The insertion point y​​

​​MsgBox (data.AtDouble(3))​​

​​' Zoom ratio ​​

​​data.AtDouble (4)​​

​​'​​​​ When drawing pictures , Whether to participate in printing , Draw a picture ​​

​​data.AtLong (5)​​

​​' No, draw its outline mark in the document ​​

​​data.AtLong (6)​​

​​'​​​​ The width of the image in the database ​​

​​data.AtDouble (7)​​

​​' The height of the image in the database ​​

​​data.AtDouble (8)​​

​​'​​​​ Used when flashing ImageFile​​

​​data.AtString (9)​​

​​' Mark text ​​

​​data.AtString (10)​​

​​'​​​​ Dimension text height ​​

​​data.AtDouble (11)​​

​​' Color index ​​

​​data.AtLong (12)​​

​​'​​​​ modify Mark Text data .​​

​​Dim setParam As MxDrawXLib.MxDrawResbuf​​

​​Set setParam = New MxDrawXLib.MxDrawResbuf​​

​​' Input object id​​

​​setParam.AddLong lId​​

​​'​​​​ Enter the new text content of the object ​​

​​setParam.AddString ​​​​"Text"​​

​​setParam.AddString ​​​​" Object is modified "​​

​​' Enter the new text height of the object ,TextHeight Yes, set tag ​​

​​setParam.AddString "TextHieght"​​

​​'​​​​ Text height value ​​

​​setParam.AddDouble 50​​

​​MxDrawX1.CallEx ​​​​"Mx_SetImageMarkData"​​​​, setParam​​
