PHP FPM custom ZABBIX monitoring

Customize php-fpm zabbix Monitoring template
According to the above experiment
In the device 1、 equipment 2 On the basis of
equipment 1 192.168.70.10 zabbix-server
equipment 2 192.168.70.20 zabbix-agent

equipment 2：
install php-rpm service

[[email protected]]# yum -y install php-fpm

modify php-fpm The configuration file opens the status page function （ Search for ：status）

[[email protected]]# vim /etc/php-fpm.d/www.conf
pm.status_path = /php_status  # Uncomment and rename php_status

start-up php-fpm

[[email protected]]# systemctl start php-fpm

Set power on self start

[[email protected]]#systemctl enable php-fpm

modify nginx The configuration file specifies php To configure （Ctrl+v Decline in Visual block appears uncomment ）

[[email protected]]#vim /etc/nginx/conf.d/default.conf
……
location /php_status {      # Appoint php page   name
       root                 html;
       fastcgi_pass   127.0.0.1:9000;
       fastcgi_index     index.php;
       fastcgi_param    SCRIPT_FILENAME   /scripts$fastcgi_script_name; # Configuration environment
       include fastcgi_params;
  }

restart nginx

[[email protected]]#systemctl restart nginx

Test access php Status page ：http://192.168.70.20/php_status

php-fpm status Detailed explanation of status value
pool：fpm Pool name , Most of them are www
process manager： Process management , value ：static,dynamic or ondemand
start time： Start date , If reload 了 php-fpm, Time will be more   new
start since： Run time
accepted conn： The number of requests currently accepted by the pool
listen queue： Request waiting queue , If the value is not 0, Then increase   Add FPM The number of processes
max listen queue： The highest number of request waiting queues
listen queue len：socket Waiting queue length
idle processes： Number of idle processes
active processes： Number of active processes
total processes： Total number of processes
max active processes： Maximum number of active processes （FPM Start on   Initial calculation ） max children reached： The number of times the maximum number of processes is limited , If this   The number of pieces is not 0, That means your maximum number of processes is too small , It needs to be set larger
slow requests  When enabled php-fpm slow-log When the function , Such as   Fruit appears php-fpm The slow request counter will increase , Generally inappropriate Mysql check   Inquiry will trigger this value

Customize phpfpm Monitoring item （ Monitor the above status ）

[[email protected] script]# vim/etc/zabbix/zabbix_agentd.d/phpfpm_status.conf UserParameter=phpfpm_status[*],/bin/bash /etc/zabbix/script/phpfpm_status.sh "$1"

Upload the script to /etc/zabbix/script Path and add execution permission

[[email protected] script]#/etc/zabbix/script
[[email protected] script]#ls
phpfpm_status.sh
[[email protected] script]# cat phpfpm_status.sh
#!/bin/bash

PHPFPM_COMMAND=$1
# Adjust according to different listening ports
PHPFPM_PORT=80

start_since(){

    /usr/bin/curl -s "http://127.0.0.1:"$PHPFPM_PORT"/php_status" |awk '/^start since:/ {print $NF}'
}
accepted_conn(){

    /usr/bin/curl -s "http://127.0.0.1:"$PHPFPM_PORT"/php_status" |awk '/^accepted conn:/ {print $NF}'
}
listen_queue(){

    /usr/bin/curl -s "http://127.0.0.1:"$PHPFPM_PORT"/php_status" |awk '/^listen queue:/ {print $NF}'
}
max_listen_queue(){

    /usr/bin/curl -s "http://127.0.0.1:"$PHPFPM_PORT"/php_status" |awk '/^max listen queue:/ {print $NF}'
}
listen_queue_len(){

    /usr/bin/curl -s "http://127.0.0.1:"$PHPFPM_PORT"/php_status" |awk '/^listen queue len:/ {print $NF}'
}
idle_processes(){

    /usr/bin/curl -s "http://127.0.0.1:"$PHPFPM_PORT"/php_status" |awk '/^idle processes:/ {print $NF}'
}
active_processes(){

    /usr/bin/curl -s "http://127.0.0.1:"$PHPFPM_PORT"/php_status" |awk '/^active processes:/ {print $NF}'
}
total_processes(){

    /usr/bin/curl -s "http://127.0.0.1:"$PHPFPM_PORT"/php_status" |awk '/^total processes:/ {print $NF}'
}
max_active_processes(){

    /usr/bin/curl -s "http://127.0.0.1:"$PHPFPM_PORT"/php_status" |awk '/^max active processes:/ {print $NF}'
}
max_children_reached(){

    /usr/bin/curl -s "http://127.0.0.1:"$PHPFPM_PORT"/php_status" |awk '/^max children reached:/ {print $NF}'
}
slow_requests(){

    /usr/bin/curl -s "http://127.0.0.1:"$PHPFPM_PORT"/php_status" |awk '/^slow requests:/ {print $NF}'
}
case $PHPFPM_COMMAND in
	start_since)
		start_since;
		;;
	accepted_conn)
		accepted_conn;
		;;
	listen_queue)
		listen_queue;
		;;
	max_listen_queue)
		max_listen_queue;
		;;
	listen_queue_len)
		listen_queue_len;
		;;
	idle_processes)
		idle_processes;
		;;
	active_processes)
		active_processes;
		;;
        total_processes)
                total_processes;
                ;;
        max_active_processes)
                max_active_processes;
                ;;
        max_children_reached)
                max_children_reached;
                ;;
        slow_requests)
                slow_requests;
                ;;
	      *)
		echo $"USAGE:$0 {start_since|accepted_conn|listen_queue|max_listen_queue|listen_queue_len|idle_processes|active_processes|total_processes|max_active_processes|max_children_reached}"
    esac

Script Authorization

[[email protected] script]# chmod +x phpfpm_status.sh

restart zabbix agent Service monitoring items take effect

[[email protected] script]# systemctl restart zabbix-agent

Turn on php-rpm

[[email protected] script]# systemctl restart php-fpm

Check the server

[[email protected] script]# netstat -ntlp

equipment 1

analysis

[[email protected]]#vim /etc/hosts
192.168.70.20   host-20

zabbix server Get monitoring item data

[[email protected]]#zabbix_get -s 192.168.0.111 -k phpfpm_status[start_since] #php-fpm Runtime   Long
[[email protected]]#zabbix_get -s 192.168.0.111 -k phpfpm_status[accepted_conn] # Current number of connections received
[[email protected]]#zabbix_get -s 192.168.0.111 -k phpfpm_status[listen_queue] # Number of requests waiting to connect
[[email protected]]# zabbix_get -s 192.168.0.111 -k phpfpm_status[max_listen_queue] # The request waiting queue is the highest   The number of
 [[email protected]]#zabbix_get -s 192.168.0.111 -k phpfpm_status[listen_queue_len] #socket Waiting in line   length
 [[email protected]]#zabbix_get -s 192.168.0.111 -k phpfpm_status[idle_processes] # Number of idle processes  ` Insert a code chip here `
 [[email protected]]#zabbix_get -s 192.168.0.111 -k phpfpm_status[active_processes] # Number of active processes
 [[email protected]]#zabbix_get -s 192.168.0.111 -k phpfpm_status[total_processes] # Total number of processes
 [[email protected]]#zabbix_get -s 192.168.0.111 -k phpfpm_status[max_active_processes] # The most active   Number of processes
 [[email protected]]#zabbix_get -s 192.168.0.111 -k phpfpm_status[max_children_reached] # Maximum number of processes   Quantity limit times
 [[email protected]]#zabbix_get -s 192.168.0.111 -k phpfpm_status[slow_requests] #php-fpm slow   request

To configure ——> Templates ——> Create a template

In the newly created template ——> establish Application set


In the new template ——> establish Monitoring item

Monitoring item name ：php-fpm Run time
type ： client
Key value ：phpfpm_status[start_since]（ Select the name in the script ）
Message type ： Numbers ( No plus or minus ) （ Those involving decimals are Floating point numbers ）
Update interval ：1m （ Express 1 minute ）
How long the historical data is kept ：7d（7 God ）
Trend storage time ：365d（365 God ）
Application set ：PHP （ Our new building ）

add to

Add other data in the script in turn

Add to complete

complete
