HCIA_ Nat experiment

Experimental questions

Topology

experimental analysis ：

1、 Only one public ip Need to pass through http Access to two servers , To do port mapping

2、 Access the server through the domain name , So we need one dns The server

Specific configuration content ：

R1:
[Huawei]sysname r1
[r1]int g0/0/0
[r1-GigabitEthernet0/0/0]ip add 192.168.1.1 24
[r1-GigabitEthernet0/0/0]int g 0/0/1
[r1-GigabitEthernet0/0/1]ip add 12.1.1.1 24
[r1-GigabitEthernet0/0/1]q
[r1]acl 2000
[r1-acl-basic-2000]rule permit source 192.168.1.2 0.0.0.0
[r1-acl-basic-2000]int g0/0/0
[r1-GigabitEthernet0/0/0]int g0/0/1
[r1-GigabitEthernet0/0/1]nat outbound 2000
[r1-GigabitEthernet0/0/1]nat server protocol tcp global current-interface 80 ins
ide 192.168.1.10 80
Warning:The port 80 is well-known port. If you continue it may cause function fa
ilure.
Are you sure to continue?[Y/N]:y
[r1-GigabitEthernet0/0/1]nat server protocol tcp global current-interface 8080 i
nside 192.168.1.20 80

ISP：

[Huawei]sysname lsp
[lsp]int g0/0/0
[lsp-GigabitEthernet0/0/0]int g 0/0/1
[lsp-GigabitEthernet0/0/1]ip add 12.1.1.2 24
[lsp-GigabitEthernet0/0/1]int g0/0/0
[lsp-GigabitEthernet0/0/0]ip add 1.1.1.1 24

various pc To configure

pc1

http1、http2

 pc2

 dns

verification ：

pc1 You can visit pc2

 2、CLIENT Can pass http visit server
