Filter/split/sideoutput comparison of Flink diversion

Streaming scene

We often encounter such scenes in production practice , You need to split the input source as needed , For example, I expect to split user access logs according to the geographical location of visitors . How to operate in the face of such a demand ？

Generally speaking, for different scenarios , There are three ways to split streams .

• Filter shunt
• Split shunt
• SideOutPut shunt


1. Filter shunt

Scala Case study

/** * Flink The way of diversion  * 1. Filter  shunt （ The original stream is filtered many times , Lead to consumption performance ） * 2. Split  shunt （ Secondary diversion is not supported ） * 3. SideOutput  shunt （ The official recommendation ） */
object filterStreamExample {

	  def main(args: Array[String]): Unit = {

		    val env = StreamExecutionEnvironment.getExecutionEnvironment
		    env.setParallelism(1)

		    //1,2011-01-01,1,0,1,0,6,0,2,0.344167,0.363625,0.805833,0.160446,331,654,985
		    //2,2011-01-02,1,0,1,0,0,0,2,0.363478,0.353739,0.696087,0.248539,131,670,801
		    val inputStream: DataStream[String] = env.readTextFile("/home/rjxy/zlp/Code/CodePro/GuoSai/Task01/src/main/resources/day.csv")

		    val littleStream = inputStream.filter(_.split(",")(0).toInt < 500)
		    val bigStream = inputStream.filter(_.split(",")(0).toInt >= 500)

		    // Print the results
		    littleStream.print("little------")
		    bigStream.print("big------")
		    env.execute()
	  }
}

 Output results ：
little------> 496,2012-05-10,2,1,5,0,4,1,1,0.505833,0.491783,0.552083,0.314063,1026,5546,6572
little------> 498,2012-05-12,2,1,5,0,6,0,1,0.564167,0.544817,0.480417,0.123133,2622,4807,7429
little------> 499,2012-05-13,2,1,5,0,0,0,1,0.6125,0.585238,0.57625,0.225117,2172,3946,6118
big------> 500,2012-05-14,2,1,5,0,1,1,2,0.573333,0.5499,0.789583,0.212692,342,2501,2843
big------> 501,2012-05-15,2,1,5,0,2,1,2,0.611667,0.576404,0.794583,0.147392,625,4490,5115

Filter The shortcomings of ：

Filter The disadvantages of ： In order to get the stream data we need , You need to traverse the original stream multiple times , This virtually wastes our cluster resources .

2. Split shunt

Scala Case study

object splitStreamExample {

  def main(args: Array[String]): Unit = {

	    val env = StreamExecutionEnvironment.getExecutionEnvironment
	// env.setParallelism(1)

	    //1,2011-01-01,1,0,1,0,6,0,2,0.344167,0.363625,0.805833,0.160446,331,654,985
	    //2,2011-01-02,1,0,1,0,0,0,2,0.363478,0.353739,0.696087,0.248539,131,670,801
	    val inputStream: DataStream[String] = env.readTextFile("/home/rjxy/zlp/Code/CodePro/GuoSai/Task01/src/main/resources/day.csv")

	    val splitStream: SplitStream[String] = inputStream.split(new OutputSelector[String] {

	      override def select(out: String): lang.Iterable[String] = {

	        val tags = new util.ArrayList[String]()
	        if (out.split(",")(0).toInt < 500) {

	          tags.add("littleStream")
	        } else if (out.split(",")(0).toInt >= 500) {

	          tags.add("bigStream")
	        }
	        return tags
	      }
	    })

	    splitStream.select("littleStream").print("little------")
	    splitStream.select("bigStream").print("big------")

	    env.execute()
  }
}

 Output results ：
little------:13> 36,2011-02-05,1,0,2,0,6,0,2,0.233333,0.243058,0.929167,0.161079,100,905,1005
little------:15> 137,2011-05-17,2,0,5,0,2,1,2,0.561667,0.538529,0.837917,0.277354,678,3445,4123
little------:13> 37,2011-02-06,1,0,2,0,0,0,1,0.285833,0.291671,0.568333,0.1418,354,1269,1623
big------:9> 592,2012-08-14,3,1,8,0,2,1,1,0.726667,0.676779,0.686667,0.169158,1128,5656,6784
little------:13> 38,2011-02-07,1,0,2,0,1,1,1,0.271667,0.303658,0.738333,0.0454083,120,1592,1712
big------:9> 593,2012-08-15,3,1,8,0,3,1,1,0.706667,0.654037,0.619583,0.169771,1198,6149,7347

Split The shortcomings of ：

But be careful , Use split The stream cut by the operator , It's impossible to do a second segmentation , If the above-mentioned cut out littleStream and bigStream The stream calls again split segmentation , The console will throw the following exception .

Exception in thread “main” java.lang.IllegalStateException:
Consecutive multiple splits are not supported. Splits are deprecated.
Please use side-outputs.

What's the reason for this ？ We can see comments in the source code , This method has been abandoned and it is recommended to use the latest SideOutPut Shunt operation .

3. SideOutPut shunt

SideOutPut yes Flink The framework provides us with the latest and most recommended diversion methods , In the use of SideOutPut when , You need to follow these steps ：
• Definition OutputTag
• Call a specific function to split data
• ProcessFunction
• KeyedProcessFunction
• CoProcessFunction
• KeyedCoProcessFunction
• ProcessWindowFunction
• ProcessAllWindowFunction
Here we use ProcessFunction How to use it SideOutPut：

Scala Case study

object sideOutStreamExample {

  def main(args: Array[String]): Unit = {

	    val env = StreamExecutionEnvironment.getExecutionEnvironment
	// env.setParallelism(1)

	    //1,2011-01-01,1,0,1,0,6,0,2,0.344167,0.363625,0.805833,0.160446,331,654,985
	    //2,2011-01-02,1,0,1,0,0,0,2,0.363478,0.353739,0.696087,0.248539,131,670,801
	    val inputStream: DataStream[String] = env.readTextFile("/home/rjxy/zlp/Code/CodePro/GuoSai/Task01/src/main/resources/day.csv")

	    // Define two OutTag
	    val littleOutTag = new OutputTag[String]("littleStream")
	    val bigOutTag = new OutputTag[String]("bigStream")

	    val processStream = inputStream.process(new ProcessFunction[String, String] {

	      override def processElement(i: String,
	                                  context: ProcessFunction[String, String]#Context,
	                                  out: Collector[String]): Unit = {

	        if (i.split(",")(0).toInt < 500) {

	          context.output(littleOutTag, i)
	        } else if (i.split(",")(0).toInt >= 500) {

	          context.output(bigOutTag, i)
	        }
	      }
	    })

	    val littleStream = processStream.getSideOutput(littleOutTag)
	    val bigStream = processStream.getSideOutput(bigOutTag)

	    littleStream.print("little------")
	    bigStream.print("big------")

	    env.execute()
  }
}

 Output results ：
big------:15> 682,2012-11-12,4,1,11,1,1,0,1,0.485,0.475383,0.741667,0.173517,1097,5172,6269
little------:4> 184,2011-07-03,3,0,7,0,0,0,2,0.716667,0.668575,0.6825,0.228858,2282,2367,4649
big------:15> 683,2012-11-13,4,1,11,0,2,1,2,0.343333,0.323225,0.662917,0.342046,327,3767,4094
little------:4> 185,2011-07-04,3,0,7,1,1,0,2,0.726667,0.665417,0.637917,0.0814792,3065,2978,6043

You can see , We split the flow , And successfully printed out the results . Pay attention here ,Flink The latest offer SideOutPut Method split flow can be split multiple times , There is no need to worry about an exception .

summary

1. Filter shunt （ The original stream is filtered many times , Lead to consumption performance ）
2. Split shunt （ Secondary diversion is not supported ）
3. SideOutput shunt （ The official recommendation ）
