Preface

Some time ago , Former colleagues asked me ,Mysql Can I import it 3 Billion of data . My mind was in a daze , I'm not sure that it should be able to import ！ Just import it in , The query may be too slow .

So Baidu immediately , I found that someone had done such a thing , stay Mysql Import 100 million level data above （ The article links ）. According to the introduction of this article , I know the original pits .

The first thing to note ： Indexes

The first thing to note is the index . When creating a table, do not index other fields except the primary key . Because the index also needs to be created , When we have too much data, we should pay attention to , Creating an index at this time will cause our data import time to be infinitely longer . Just leave a self increasing ID Just make the primary key , If your data has a primary key （ Absolutely unique ）, Just use this primary key , There is no need to increase ID 了 . When the import is complete , We are adding indexes .

The second note ： Storage engine

Mysql Generally, it is recommended to use InnoDB, But here we have no business needs , Therefore, a more efficient query MyISAM As a storage engine . It should be noted that MyISAM There is no business , Just insert , There is no saying of rollback . It should be noted that the table is locked when writing 、 So when writing , Don't query the data of the table at the same time .

The third note ： disk space

Be sure to leave enough space for your disk before inserting . It should be noted that there are large transactions in the import , exceed binlog_cache_size, High and send to generate a large number of temporary files （ Links to articles ）, If we do not specify a temporary file directory , So if you are windows System , Your temporary file directory is probably in C disc . have access to show variables like "tmpdir"; Command to see where your own temporary directory is . If there is not enough space, an error will be reported ：1598 - Binary logging not possible. Message: An error occurred during flush stage of the commit. 'binlog_error_action' is set to 'ABORT_SERVER'. Hence aborting the server. So it's best to specify the directory of temporary files tmpdir="D:/Program Files/db/mysql-8.0.20-winx64/tmp"

Data preparation

Okay 、 Start the import journey . Before importing, we need to prepare the corresponding data , Here, first post the table structure ：

create table test_user_tab(
id bigint comment ' Primary key ',
now_date varchar(20) comment ' Insert time ',
tel varchar(11) comment ' Telephone ',
card_num varchar(18) comment ' ID number ',
sex int comment ' Gender ：1 male ,0 Woman ',
mz varchar(20) comment ' Famous people ',
user_name varchar(20) comment ' full name ',
address_str varchar(50) comment ' Address ',
PRIMARY KEY (`id`)
) ENGINE=MyISAM DEFAULT CHARSET=utf8 comment ' User test form ';

We can use code to generate corresponding data , Randomly generated phone 、 ID number 、 Gender 、 nation 、 full name 、 Address . Generate 300 million data at a time .

java Generate the data

Generate code warehouse ： Test data generation : Generate test data

import com.hzw.code.util.IDCardUtil;
import com.hzw.code.util.RandomValue;
import com.hzw.code.util.WeightRandomMz;
import org.apache.commons.lang3.time.DateFormatUtils;

import java.io.FileNotFoundException;
import java.io.FileOutputStream;
import java.io.IOException;
import java.nio.ByteBuffer;
import java.nio.channels.FileChannel;
import java.util.Date;

public class Test {

    public static void main(String[] args) {
        int sex = 0;
        String card = null;
        int c = 1;
        for(int k=1;k<=3000; k++) {
            StringBuffer sbText = new StringBuffer();
            for (int i = 1; i <= 100000; i++) {
                card = IDCardUtil.generateID();
                if (Integer.parseInt(card.substring(16, 17)) % 2 == 1) {
                    sex = 1;
                } else {
                    sex = 0;
                }
                sbText.append(c++).append(",").
                        append(DateFormatUtils.format(new Date(), "yyyy-MM-dd HH:mm:ss")).
                        append(",").append(RandomValue.getTel()).
                        append(",").append(card).
                        append(",").append(sex).
                        append(",").append(WeightRandomMz.getMz()).
                        append(",").append(RandomValue.getChineseName()).
                        append(",").append(RandomValue.getRoad()).append("\n");
                System.out.println(" The current number ："+c);
            }
            write("D:\\app\\ld\\users_data.txt", sbText.toString());
        }
    }


    /**
     *  Append write file
     * @param file   File path
     * @param text   Appending the content of writing
     */
    public static void write(String file,String text) {
        FileOutputStream fos = null;
        FileChannel channel = null;
        try {
            fos = new FileOutputStream(file,true);
            channel = fos.getChannel();
            byte[] array = text.getBytes();
            ByteBuffer buffer = ByteBuffer.wrap(array);
            channel.write(buffer);
        } catch (FileNotFoundException e) {
            e.printStackTrace();
        } catch (IOException e) {
            e.printStackTrace();
        } finally {
            try {
                channel.close();
                fos.close();
            } catch (IOException e) {
                e.printStackTrace();
            }
        }
    }
}

Import data

According to the above java Code , We got 3 100 million data , pure txt File size is ：27.7GB. At this time, you can start importing . The table structure has been posted on it , Import according to the above structure .

load data local infile 'D:/app/ld/users_data.txt' into table test_user_tab
CHARACTER SET utf8 --  Optional , Avoid the problem of Chinese random code
FIELDS TERMINATED BY ',' --  Field separator , Each field ( Column ) What characters are used to separate , The default is  \t
 OPTIONALLY ENCLOSED BY '' --  Text qualifier , What characters are enclosed in each field , The default is null
 ESCAPED BY '\\' --  Escape character , The default is  \
LINES TERMINATED BY '\n' --  Record separator , For example, the field itself also contains \n, Then you should remove , otherwise load data  It will be mistakenly imported as another line of record
(id, now_date, tel, card_num, sex,mz,user_name,address_str) --  The table fields corresponding to each line of text in order , It is recommended not to omit

After executing the above code, an error may be reported Loading local data is disabled; this must be enabled on both the, You need to enable global local file settings

set global local_infile=on;

So this edition needs to wait

After import 、 The size of the table ：

         Index length （4.03GB）、 Data length （29.13GB）、 Maximum data length （256TB）

Notebook configuration ：

         Memory ：16G

        CPU：AMD RYZEN 5 3500U 4 nucleus

         Solid state disk ：500G

SQL test ：Count Why can the whole watch be spicy so fast 、 Because MyISAM The engine will store the number of data entries of the whole table ,Count The whole table will be stored directly count Get it .

mysql> select * from test_user_tab
order by id desc limit 0,10;
+-----------+---------------------+-------------+--------------------+-----+--------+-----------+----------------------+
| id        | now_date            | tel         | card_num           | sex | mz     | user_name | address_str          |
+-----------+---------------------+-------------+--------------------+-----+--------+-----------+----------------------+
| 300000000 | 2021-06-30 10:28:34 | 13501545216 | 410101196604012797 |   1 |  dulong    |  Huqidong     |  Market 2 building 15 Number -15-8  |
| 299999999 | 2021-06-30 10:28:34 | 13203729048 | 140101201101183795 |   1 |  Bouyei    |  Lu Cheng       |  Minjiang second square 50 Number -1-6   |
| 299999998 | 2021-06-30 10:28:34 | 13107976886 | 220101201409017312 |   1 |  Bouyei    |  Xu Yan       |  Zhangping road 65 Number -11-5      |
| 299999997 | 2021-06-30 10:28:34 | 13405130128 | 530101198901051473 |   1 |  Maonan    |  Gong guohan     |  Dagang Weisi Street 122 Number -5-10 |
| 299999996 | 2021-06-30 10:28:34 | 13500788582 | 310101195005203737 |   1 |  han      |  Guo Fang       |  Macau Plaza 118 Number -16-1   |
| 299999995 | 2021-06-30 10:28:34 | 13500938547 | 540101200801079200 |   0 |  Naxi    |  Gongyun       |  Weixian square 46 Number -6-7     |
| 299999994 | 2021-06-30 10:28:34 | 15301675632 | 810101195409066773 |   1 |  Tatar  |  Che Qian       |  Fukuyama building 13 Number -15-5    |
| 299999993 | 2021-06-30 10:28:34 | 15502277286 | 120101200506094119 |   1 |  Maonan    |  Xuan Yanguang     |  Xiaogang Second Street 111 Number -17-2   |
| 299999992 | 2021-06-30 10:28:34 | 15307933706 | 620101199804149598 |   1 |  han      |  Su Qi       |  Wusong Road 101 Number -20-4     |
| 299999991 | 2021-06-30 10:28:34 | 13808373641 | 320101199212197480 |   0 |  hidden      |  Fan Jihua     |  Wuding Road 142 Number -9-5      |
+-----------+---------------------+-------------+--------------------+-----+--------+-----------+----------------------+
10 rows in set (0.19 sec)

mysql> select * from test_user_tab where id in (569866,5656,23565,44,6,6467,8979);
+--------+---------------------+-------------+--------------------+-----+------+-----------+---------------------+
| id     | now_date            | tel         | card_num           | sex | mz   | user_name | address_str         |
+--------+---------------------+-------------+--------------------+-----+------+-----------+---------------------+
|      6 | 2021-06-30 09:14:24 | 13704555009 | 110101199102178730 |   1 |  return    |  Xu Liang       |  Xinchang Street 148 Number -1-2     |
|     44 | 2021-06-30 09:14:24 | 15101051329 | 430101200205272631 |   1 |  Susu  |  Chu Huijia     |  Haiyang Road 76 Number -11-6     |
|   5656 | 2021-06-30 09:14:24 | 15604920061 | 440101201702236208 |   0 |  han    |  Ru Yongtian     |  Wuxian 1st Street 119 Number -5-3   |
|   6467 | 2021-06-30 09:14:24 | 15505384583 | 520101196903158281 |   0 |  North Korea  |  Yangguangsheng     |  Xinzhan road 133 Number -8-5     |
|   8979 | 2021-06-30 09:14:24 | 13007372278 | 110101202107103898 |   1 |  full    |  Gong Yun       |  Huimin South Road 65 Number -9-6    |
|  23565 | 2021-06-30 09:14:24 | 13103003467 | 440101197306079977 |   1 |  Dai nationality    |  Ge Fengting     |  Macao 4th Street 51 Number -17-9   |
| 569866 | 2021-06-30 09:14:33 | 15603042860 | 32010119830925634X |   0 |  han    |  Rong juanlu     |  Dagang Weiyi road 52 Number -14-9 |
+--------+---------------------+-------------+--------------------+-----+------+-----------+---------------------+
7 rows in set (0.21 sec)

Just use id As a condition , Because of the index , Pretty fast . Other fields are not so hot . Need to do where Add an index to the field of the condition .
